| CADI, MAGIC5, MAGIC7 MONITOR |
 |
 |
 |
| Specifications | Features CADI | Features MAGIC5 | Features MAGIC7 |
| CRT Size/Type | 14"CONVENTIONAL 0.28mm NON-GLARE P22 |
15"FST(14" viewable),Invar mask, dark glass faceplate 0.28 mm Dot Non-glare,anti-static,silica coating P22,medium short persistence |
17"FST(15.9 viewable),Invar mask ark glass faceplate 0.28 mm Dot Non-glare,anti-static,silica coating P22,medium short persistence |
| Display MAX | 250mm * 180mm | 280mm * 210mm | 330mm * 245mm |
| Maximum flicker-free Resolution |
640 * 480 / 72Hz NI 800 * 600 / 60Hz NI 1024 *768 NI |
640 * 480 /100Hz NI 800 * 600 /100Hz NI 832 * 624 /75Hz NI(Mac) 1024 * 768 /80Hz NI |
640 * 480 /100Hz NI 800 * 600 /100Hz NI 832 * 624 /75Hz NI(Mac) 1024 * 768 /80Hz NI |
| Maximum Resolution | 1024*768(NON-INTERLA ACED) | 1280*1024/60Hz NI | 1280*1024/60Hz NI |
| Display Capability | Auto-sync within scan frequencies | Auto-sync within scan frequencies | Auto-sync within scan frequencies |
| Horizonal Scanning Frequencies |
30-48KHz | 30-70KHz | 30-70KHz |
| Vertical Scanning Frequencies |
50-90Hz | 50-120Hz | 50-120Hz |
| Sync signaling | Separate horizontal/vertical | Separate horizontal/vertical | Separate horizontal/vertical |
| Band Width | 65MHz | 100MHz | 100MHz |
| Cable Connector | 15pin D-sub with 48-inch cable | 15pin D-sub with 48-inch cable | 15pin D-sub with 48-inch cable |
| Monitor Control Type | digital micropressor OSD control | digital micropressor OSD control | |
| Memory Modes | 13 factory presets 6 user settable | 13 factory presets 6 user settable | |
| Vesa plug play level | DDC2B(optional) | DDC2B(optional) | |
| Front Panel Buttons | Power,Menu,Selet,Up,Down | Power,Menu,Selet,Up,Down | |
| On-Screen ADJ | Horizonal/Vertical Size and Position, sidepincushion, trapezoid, bright & contrast(Not) |
Horizonal/Vertical Size and Position, sidepincushion, trapezoid Color temper-ature and RGB levels, bright&contrast,image tilt,manual Deguss,mode recall |
Horizonal/Vertical Size and Position, sidepincushion, trapezoid Color temper-ature and RGB levels, bright&contrast,image tilt,manual Deguss,mode recall |
| Power Requiremants | 100-240 VAC(FREE VOLT)50/60Hz | 90-264 VAC,47-63Hz | 90-264 VAC,47-63Hz |
| Power Consumption | MAX 70 Watts | 90 Watts max,utilizes DPMS | 100W max,utilizes DPMS* |
| DPMS Power cons~ on: Stand-by: Suspend: DPMS Off: |
70W :green power LED 60W:amber Led 25W:amber/green LED(1sec) 8W:amber/green LED(2sec) |
80W :green power LED 65W:amber Led 25W:amber/green LED(1sec) 8W:amber/green LED(2sec) |
100W :green power LED 65W:amber Led 25W:amber/green LED(1sec) 8W:amber/green LED(2sec) |
| Tilt/Swivel Base | Included , detachable | ncluded , detachable | |
| Dimensions(W*H*D) | 14" 362*387*321 | 15" 370*410*415 | 17" 410*405*420 |
| Weight Net | 12.5Kg | 14Kg | 14.5Kg |
| Mean Time Between | 50,000 hours | 50,000 hours | 50,000 hours |
| Safety/Regulatory | UL,CAS,FCC-B,DHHS | UL,CAS,FCC-B,DHHS | UL,CAS,FCC-B,DHHS |
